Sub-threshold nanosecond laser (SNL) treatment in intermediate AMD (IAMD)

Sub-threshold nanosecond laser (SNL) treatment in intermediate AMD (IAMD)

R. Theodore Smith

New York Eye and Ear Infirmary of Mount Sinai, New York City, NY, USA

Correspondence to: R. Theodore Smith. New York Eye and Ear Infirmary of Mount Sinai, New York City, USA. Email:

Comment on: Guymer RH, Wu Z, Hodgson LAB, et al. Subthreshold Nanosecond Laser Intervention in Age-Related Macular Degeneration: The LEAD Randomized Controlled Clinical Trial. Ophthalmology 2018. [Epub ahead of print].

Received: 12 December 2018; Accepted: 30 December 2018; Published: 10 January 2019.

doi: 10.21037/aes.2018.12.04


The Laser intervention in early stages of age-related macular degeneration (LEAD) study (1) is a 36-month, multicenter, randomized, sham-controlled trial conducted from 2012–2015 of 292 participants with bilateral soft drusen, aka intermediate AMD (iAMD), who underwent q 6-month treatment with sub-threshold nanosecond laser (SNL) or sham treatment to the study eye.

The primary efficacy outcome was the time to develop late AMD [geographic atrophy (GA) or choroidal neovascularization (CNV)] defined by multimodal imaging (MMI), which comprised spectral domain optical coherence tomography (SD-OCT), autofluorescence imaging (AF) and near-infrared reflectance imaging (NIR-R). Although progression to late AMD was not significantly slowed with SNL compared to sham for the entire group, post-hoc analysis showed a significant benefit to those subjects without reticular pseudodrusen (RPD), and a worse outcome for those subjects with RPD, aka subretinal drusenoid deposits (SDD). SNL treatment may thus have a role in slowing progression for subjects without coexistent RPD/SDD and may be inappropriate in those with RPD/SDD. Further study is clearly warranted.

The important questions

A historically important question is examined in this paper. Is there a role for laser intervention in iAMD? There is a checkered history of laser for drusen from prior literature. Despite the fact that macular thermal laser caused drusen resorption (2), some studies showed that even light thermal burns could lead to worse visual outcomes than observation (3). A Cochrane review of such studies later concluded that although drusen regression did occur, there was no reduction or increase in progression to late AMD (4). Subthreshold treatment herein reasonably explores the lower end of the dose-response curve to seek safety while still maintaining a therapeutic response.

It is also important to recognize that the 2RT laser is quite novel in the realm of retinal therapy. It is a non-thermal device that delivers single pulse Q-switched neodymium yttrium aluminum garnet (Nd-YAG) laser at a wavelength of 532 nm with pulse duration of 3 ns (5). The laser spot size is fixed at 400 µm diameter, with a fine speckle energy distribution beam profile. The treatment spots are placed just inside the arcades and the treatment energy is approximately 1,000 times less than is used in thermal laser treatment to the macula for diabetic macular edema and uses pulses approximately 33,000,000 times shorter in duration (5). Animal and tissue models demonstrate that such treatment has a measurable effect on RPE melanin, with cytokine up-regulation and on melanin granules themselves (6). So compared with previous thermal laser in the macula, we are in completely new biophysical territory.

What about other lasers? In fact, subthreshold micropulse laser, though not 2RT, and not nano-second laser, has been widely used in diabetic retinopathy with diabetic macular edema (DME) and other retinal diseases (7), and its effects have been studied with OCTA (8). It is also claimed that these lasers spare the neurosensory retina and are selectively absorbed by the RPE. One meta-analysis of 6 randomized controlled trials for DME demonstrated superior visual outcome over conventional laser, although the differences were thought likely to be too small to be of clinical relevance (9). As for AMD, one retrospective study of subthreshold micropulse laser in dry AMD eyes found a low incidence CNV over 2 years (10), but the entrance criteria and treatment parameters were not well-specified, and there was no control group.

Finally, in the present study, the post hoc analysis also delivered an unexpected and important message about the two main phenotypes of iAMD, soft drusen and RPD aka subretinal drusenoid deposits (SDD). It showed a marked division between outcomes for eyes with and without RPD. Progression was slowed for the 222 (76.0%) participants without coexistent RPD/SDD at baseline, while an increased progression rate was observed for the 70 (24.0%) participants with RPD/SDD. These observations together suggest that there may be a therapeutic effect of nano-pulse laser in iAMD as long as the eye is not burdened with RPD/SDD, despite the fact that the study was not designed to test this hypothesis. Indeed, the high-risk phenotype of RPD/SDD may in fact be a contra-indication for such treatment.

The role of RPD/SDD

To understand why RPD/SDD could make such a difference, it is necessary to understand the significantly adverse impact in general on AMD and vision they convey compared to large soft drusen. RPD/SDD are common, and are also the highest risk phenotype of intermediate AMD, doubling the rate of conversion to advanced AMD over soft drusen alone (11). SDD are associated with choroidal thinning (12,13), suggesting vascular insufficiency at the outer retina as the second component of a combined phenotype with lesions in two compartments, subretinal and choroidal. For this reason, the term reticular macular disease (RMD) (14) was advanced to convey a more complex disease process than SDD alone, and to help explain the increased morbidity of this phenotype. For example, RMD is linked to GA progression and is a strong spatial determinant of the subsequent expansion of GA locally (15,16). Indeed, there is a nearly universal association of RMD with the multilobular, and fastest growing, phenotype of GA, which led us to hypothesize that they are a continuum of a single disease process, perhaps related to an underlying lobular choroidal insufficiency (15,17).

The RPD/SDD phenotype also has a genetic correlate. The stronger association of the ARMS2 risk allele than the CFH risk allele with the SDD/RMD phenotype was first pointed out in a sub-study of the Columbia Macular Genetics Study (18,19) and has been subsequently confirmed in other studies, including a recent meta-analysis (20), and in genetic and imaging analysis of 755 subjects from the CATT trial (21).

Next, RPD/SDD are associated with marked losses of rod-mediated dark adaptation (RMDA), emphasizing damage to rod function. The pathophysiology of RMDA impairment in AMD, initially attributed mostly to age-changes in RPE-Bruch’s membrane complex, is now understood to include the presence of SDD between photoreceptors and RPE with particularly devastating effect (22-24). Like drusen, SDD also involve increased diffusion distance from the choriocapillaris and reduced transfer from the RPE, plus direct cytotoxicity to photoreceptors, which the deposits contact. Strikingly, the presence of SDD and ellipsoid zone disruption were a consistent predictor of RMDA impairment, whether located within the DA testing spot or anywhere in the macula (P<0.001 for both). The presence of classic drusen were only significantly associated with impaired RMDA if they fell within the testing spot (P≤0.018) (23).

Finally, the genetics of SDD and their adverse effect on RMDA are themselves connected, because the ARMS2 A69S risk polymorphism is independently associated with delayed RMDA, even in eyes that have not yet developed AMD! (25). This is an important link between the mysterious ARMS2 risk allele and the development and progression of AMD, with all signs so far pointing to preferential rod damage, and implicating SDD. Further, here we have a direct connection of ARMS2 with a functional deficit in dark adaptation that seems to appear before SDD, or even before any clinically evident AMD. This in turn could be consistent with radical new disease models in which the damage is done in early development.

Future steps

If we then posit that sub-threshold nanosecond laser intervention may be helpful for intermediate AMD, excluding the highest risk phenotype of RPD/SDD, the next steps forward seem clear. The findings in this study provide compelling evidence for further trials of the 2RT laser. Specifically, further trials of the 2RT laser in the large soft drusen and pigment abnormality class of iAMD are clearly warranted. Also, a careful re-examination of all available time-sequence imaging, demographic and clinical data in the original RPD/SDD subgroup should be carried out to find further clues to the apparent adverse outcome of laser treatment in this group. This might improve our understanding of the pathogenesis and adverse natural history of this high-risk phenotype.


A startlingly good outcome has now been shown in one study for treatment with sub-threshold nanosecond laser for the non-RPD/SDD phenotype of iAMD, and is contrasted with an apparently poor outcome for the RPD/SDD phenotype. It is important that we learn more about both types of iAMD from carefully phenotyped, genotyped and controlled treatment trials. Appropriate caution is of course always in order, but a sorely needed new management for early AMD may be at hand.


Funding: This work was supported in part by NIH/NEI R01EY015520.


Provenance and Peer Review: This article was commissioned by the editorial office, Annals of Eye Science. The article did not undergo external peer review.

Conflicts of Interest: The author has completed the ICMJE uniform disclosure form (available at RTS serves as the unpaid editorial board members of Annals of Eye Science from May 2019 to Apr 2021.

Ethical Statement: The author is accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See:


  1. Guymer RH, Wu Z, Hodgson LAB, et al. Subthreshold Nanosecond Laser Intervention in Age-Related Macular Degeneration: The LEAD Randomized Controlled Clinical Trial. Ophthalmology 2018; [Epub ahead of print]. [Crossref] [PubMed]
  2. Figueroa MS, Regueras A, Bertrand J. Laser photocoagulation to treat macular soft drusen in age-related macular degeneration. Retina 1994;14:391-6. [Crossref] [PubMed]
  3. Querques G, Cicinelli MV, Rabiolo A, et al. Laser photocoagulation as treatment of non-exudative age-related macular degeneration: state-of-the-art and future perspectives. Graefes Arch Clin Exp Ophthalmol 2018;256:1-9. [Crossref] [PubMed]
  4. Virgili G, Michelessi M, Parodi MB, et al. Laser treatment of drusen to prevent progression to advanced age-related macular degeneration. Cochrane Database Syst Rev 2015;CD006537 [PubMed]
  5. Guymer RH, Brassington KH, Dimitrov P, et al. Nanosecond-laser application in intermediate AMD: 12-month results of fundus appearance and macular function. Clin Exp Ophthalmol 2014;42:466-79. [Crossref] [PubMed]
  6. Jobling AI, Guymer RH, Vessey KA, et al. Nanosecond laser therapy reverses pathologic and molecular changes in age-related macular degeneration without retinal damage. FASEB J 2015;29:696-710. [Crossref] [PubMed]
  7. Terashima H, Hasebe H, Okamoto F, et al. Combination therapy of intravitreal ranibizumab and subthreshold micropulse photocoagulation for macular edema secondary to branch retinal vein occlusion: 6-month result. Retina 2018; [Epub ahead of print]. [Crossref] [PubMed]
  8. Vujosevic S, Gatti V, Muraca A, et al. Optical coherence tomography angiography changes after subthreshold micropulse yellow laser in diabetic macular edema. Retina 2018; [Epub ahead of print]. [Crossref] [PubMed]
  9. Chen G, Tzekov R, Li W, et al. Subthreshold micropulse diode laser versus conventional laser photocoagulation for diabetic macular edema: A Meta-Analysis of Randomized Controlled Trials. Retina 2016;36:2059-65. [Crossref] [PubMed]
  10. Luttrull JK, Sinclair SH, Elmann S, et al. Low incidence of choroidal neovascularization following subthreshold diode micropulse laser (SDM) in high-risk AMD. PLoS One 2018;13:e0202097 [Crossref] [PubMed]
  11. Pumariega NM, Smith RT, Sohrab MA, et al. A prospective study of reticular macular disease. Ophthalmology 2011;118:1619-25. [Crossref] [PubMed]
  12. Garg A, Oll M, Yzer S, et al. Reticular pseudodrusen in early age-related macular degeneration are associated with choroidal thinning. Invest Ophthalmol Vis Sci 2013;54:7075-81. [Crossref] [PubMed]
  13. Cheng H, Kaszubski PA, Hao H, et al. The Relationship Between Reticular Macular Disease and Choroidal Thickness. Current eye research 2016;41:1492-7. [Crossref] [PubMed]
  14. Smith RT, Sohrab MA, Busuioc M, et al. Reticular macular disease Am J Ophthalmol 2009;148:733-743.e2. [Crossref] [PubMed]
  15. Xu L, Blonska AM, Pumariega NM, et al. Reticular macular disease is associated with multilobular geographic atrophy in age-related macular degeneration. Retina 2013;33:1850-62. [Crossref] [PubMed]
  16. Marsiglia M, Boddu S, Bearelly S, et al. Association between geographic atrophy progression and reticular pseudodrusen in eyes with dry age-related macular degeneration. Invest Ophthalmol Vis Sci 2013;54:7362-9. [Crossref] [PubMed]
  17. A Martillo M, Marsiglia M, Lee MD, et al. Is reticular macular disease a choriocapillaris perfusion problem? Med Hypothesis Discov Innov Ophthalmol 2012;1:37-41. [PubMed]
  18. Hageman GS, Anderson DH, Johnson LV, et al. A common haplotype in the complement regulatory gene factor H (HF1/CFH) predisposes individuals to age-related macular degeneration. Proc Natl Acad Sci U S A 2005;102:7227-32. [Crossref] [PubMed]
  19. Smith RT, Merriam JE, Sohrab MA, et al. Complement factor H 402H variant and reticular macular disease. Arch Ophthalmol 2011;129:1061-6. [Crossref] [PubMed]
  20. Jabbarpoor Bonyadi MH, Yaseri M, Nikkhah H, et al. Association of risk genotypes of ARMS2/LOC387715 A69S and CFH Y402H with age-related macular degeneration with and without reticular pseudodrusen: a meta-analysis. Acta Ophthalmol 2018;96:e105-10. [Crossref] [PubMed]
  21. Lin LY, Zhou Q, Hagstrom S, et al. Association of Single-Nucleotide Polymorphisms in Age-Related Macular Degeneration With Pseudodrusen: Secondary Analysis of Data From the Comparison of AMD Treatments Trials. JAMA Ophthalmol 2018;136:682-8. [Crossref] [PubMed]
  22. Flamendorf J, Agron E, Wong WT, et al. Impairments in Dark Adaptation Are Associated with Age-Related Macular Degeneration Severity and Reticular Pseudodrusen. Ophthalmology 2015;122:2053-62. [Crossref] [PubMed]
  23. Laíns I, Miller JB, Park DH, et al. Structural Changes Associated with Delayed Dark Adaptation in Age-Related Macular Degeneration. Ophthalmology 2017;124:1340-52. [Crossref] [PubMed]
  24. Ooto S, Suzuki M, Vongkulsiri S, et al. Multimodal Visual Function Testing in Eyes with Nonexudative Age-Related Macular Degeneration. Retina 2015;35:1726-34. [Crossref] [PubMed]
  25. Mullins RF, McGwin G Jr, Searcey K, et al. The ARMS2 A69S Polymorphism Is Associated with Delayed Rod-Mediated Dark Adaptation in Eyes at Risk for Incident Age-Related Macular Degeneration. Ophthalmology 2018; [Epub ahead of print]. [Crossref] [PubMed]
doi: 10.21037/aes.2018.12.04
Cite this article as: Smith RT. Sub-threshold nanosecond laser (SNL) treatment in intermediate AMD (IAMD). Ann Eye Sci 2019;4:2.
